ThermTec Ventus 650L Multi-Spectrum Binocular

The Ventus 650L features a high-sensitivity thermal sensor with optimized NETD <15 mK paired with a 12-megapixel CMOS sensor, supported by switchable 850 nm and 940 nm IR illumination for reliable imaging day and night. ThermTec AI Calibration enhances image sharpness and stability for smooth viewing in dynamic environments. With balanced magnification and a detection range up to 2600 m, it enables efficient target scanning, while intuitive mode switching and ergonomic design ensure steady, comfortable observation during extended use.

Key Features Thermtec ARES 660 2.0 Thermal Riflescope

• 5-in-1 integrated vision system
• Switch from infrared to daylight mode without the need to refocus
• 640×512 thermal resolution with NETD＜15mK
• Switchable 850nm and 940nm IR for optimized night vision
• EIS-enhanced CMOS imaging stability under high magnification
• ThermTec AI Calibration for consistently stable and clear images
• Thermal Super Resolution technology for ultra-detailed thermal images
• Ergonomic design for dual focus wheel control with one hand
• Anti-slip, rubber-coated frame with widely adjustable eyepieces
• A proximity sensor enables automatic screen-off for energy savings
• Two replaceable batteries provide 6-hour durability
• Integrated LRF precision up to 1000m
• Long detection range up to 2600m
• Service & Support all-in-one App
• 4K UHD resolution of 3536×3536 on a 1600×1200 0.5″ AMOLED display

Specifications:

• Thermal Resolution: 640×512

• Pixel Pitch: 12μm

• NETD: ＜15mK@300K

• Spectral Range: 8-14μm

• Thermal Objective Lens: 50mm/F1.0

• Thermal Field of View (m @ 100m): 8.8°×7.0° / 15.4×12.3

• Frame Rate: 50Hz

• Thermal Magnification: 3.7X-14.8X(4X)

• Detection Range: 2600m

• Optical Resolution: 3536×3536, 2μm

• Optical Field of View (m @ 100m): 8.1°×8.1° / 14.14×14.14

• Optical Objective Lens: 50mm/F1.4

• IR Illuminator Wavelength: 850nm/940nm switchable

• Viewing Range at Night: 850nm: 400m / 940nm: 350m

• Optical Magnification: 4X-16X(4X)

• Display Type: AMOLED

• Image Display Resolution: 1600×1200

• Display Size: 0.5 inch

• Color Palette: 6 options

• EIS (Electronic Image Stabilization): Yes

• Eye Relief: 20mm

• Exit Pupil: 8mm

• Diopter: ±5D

• Interpupillary Adjustment Range: 60 mm to 72 mm

• Image Mode: Forest/Rainy

• TSR Algorithm: Yes

• LRF Safety Class: Class 1

• LRF Wavelength: 905nm

• LRF Range: 1000m

• LRF Accuracy: ±1m

• Photo/Video Playback: Yes

• Audio Recording: Yes

• Azimuth: Yes

• Digital Magnetic Compass: Yes

• Hotspot: Yes

• Language: Multiple languages

• Storage: 64GB EMMC

• PIP (Picture-in-Picture): Yes

• Heat Track: Yes

• Local Album: Yes

• OSD Recording: Yes

• Burn Prevention: Yes

• Internal Battery: Replaceable Li-ion battery (18650*2)

• Type-C Power Supply: Data transfer

• Battery Life: 6 hours

• Working Temperature: -20℃ to +50℃

• Protection Level: IP67

• Weight: 833g

• Size: 164(L) x 127.6(W) x 73(H) mm

• Mounting Adapter: 1/4-20-UNC
