Pulsar Axion XG35 Compact Thermal Monocular

Pulsar Axion XG35 Compact Thermal Monocular

The Pulsar Axion XG35 COMPACT Thermal Monocular combines powerful thermal imaging technology with an incredibly compact design, offering outstanding performance and portability. Whether you’re surveying large areas or tracking heat sources in the most challenging conditions, the Axion XG35 delivers clear, precise thermal imagery with unmatched ease of use.

Key Features:

• European-Made Lynred Thermal Sensor: Equipped with a high-resolution 640×480 sensor and a 12µm pixel pitch, the AXION XG35 offers exceptional thermal detail, even in the most difficult environments. With its <40mK NETD sensitivity, this monocular detects even the faintest heat signatures, ensuring reliable performance in both day and night conditions.
• Long-Range Detection with 35mm f1.0 Lens: The 35mm f1.0 germanium objective lens provides impressive detection capabilities, allowing you to spot distant objects up to 1750 meters away with remarkable clarity. This long-range performance is ideal for surveillance, wildlife observation, or search-and-rescue operations.
• Wide Field of View & High Magnification: The 12.5° field of view offers a broader perspective, making it easier to scan large areas quickly and efficiently. Combine this with the 2.5x to 20x magnification range, and the AXION XG35 allows you to zoom in on distant heat sources with fine detail, all while maintaining smooth, real-time viewing thanks to its 50Hz frame rate.
• Extended Battery Life for Prolonged Use: Powered by a removable and rechargeable Pulsar APS3 battery, the AXION XG35 offers up to 7 hours of continuous use. When you’re out in the field, you can simply swap in an extra APS3 battery to keep your observations going without interruption.
• Rugged and Weatherproof: The magnesium alloy body is designed for durability, built to withstand tough environments and rough handling. With an IPX7 waterproof rating, the AXION XG35 is fully protected against dust and water, making it suitable for use in heavy rain, snow, and even full immersion in water. Whether you’re navigating extreme outdoor conditions or dealing with unpredictable weather, this monocular is up to the task.
• Ergonomic Rubberized Grip: A newly designed rubberized grip ensures comfort and stability during long periods of use, reducing hand fatigue. Whether you’re using the device in dry or wet conditions, the ergonomic design ensures a secure, comfortable hold for extended observation sessions.
• Eight Customizable Color Palettes: The AXION XG35 features eight adjustable color palettes, allowing you to adapt the display to your specific needs. Whether you’re performing quick detection with White Hot, tracking animals with Rainbow, or conducting long-duration night observations with Red Monochrome, you can optimize your view for any situation.
• Built-In Video & Audio Recording: Capture important moments with the built-in video recorder and audio capabilities, saving your footage directly to the device’s 64GB internal memory. This feature is ideal for documenting your observations and reviewing them later. The MP4 video format and JPG image format ensure high-quality recordings that are easy to store and share.
• Stream Vision 2 Connectivity: The AXION XG35 seamlessly integrates with the Stream Vision 2 app, allowing you to remotely control the device via your smartphone or tablet. You can stream live footage, adjust settings, and even update the firmware to ensure your device remains at peak performance.
• Cloud Storage Integration: Videos and images captured with the AXION XG35 can be uploaded to the cloud via the Stream Vision 2 app, enabling easy access, sharing, and storage from anywhere.
• Stadiametric Rangefinder: The built-in stadiametric rangefinder enhances your observation capabilities by providing distance estimation, helping with targeting and tracking over long distances.

Specifications:

• Thermal Sensor: 640×480, 12µm pixel pitch, <40mK NETD
• Objective Lens: 35mm f1.0
• Frame Rate: 50 Hz
• Magnification: 2.5x to 20.0x
• Field of View (FOV): 12.5°
• Eye Relief: 14mm
• Detection Range: Up to 1750 meters
• Rangefinder: Stadiametric
• Battery: Pulsar APS3 rechargeable & replaceable
• Battery Life: Up to 7 hours
• Audio/Video: Built-in video recorder with audio, still image capture
• Internal Memory: 64GB
• Video Format: .MP4
• Video Resolution: 960×900
• Image Format: .JPG
• Image Resolution: 960×600
• Wi-Fi: Yes
• Stream Vision 2: Yes
• Body Material: Magnesium alloy
• Level of Protection: IPX7 (waterproof and dustproof)
• Operating Temperature: -25°C to +40°C
• Dimensions: 146 x 49 x 71 mm
• Weight: 350g

Features Summary:

• Compact & Lightweight: The Axion XG35 is designed to be highly portable, fitting comfortably in the palm of your hand for easy use in the field.
• High-Performance Thermal Imaging: Featuring a 640×480 Lynred thermal sensor, the device delivers exceptional thermal clarity, even in low-visibility conditions.
• Long-Range Detection: The 35mm f1.0 lens enables detection of heat sources up to 1750 meters away.
• Wide Field of View: The 12.5° field of view allows for quicker scanning of large areas.
• Extended Battery Life: Up to 7 hours of continuous operation with the Pulsar APS3 battery.
• Durable & Weatherproof: IPX7 rating ensures protection against water and dust, suitable for extreme outdoor environments.
• Ergonomic Grip: Comfortable and secure handling, even in wet conditions.
• Eight Color Palettes: Customize the display for optimal viewing in any environment.
• Built-in Video & Audio Recording: Capture high-quality footage and store it directly on the device.
• Stream Vision 2 Connectivity: Remote control, live streaming, and firmware updates via the Stream Vision 2 app.
• Cloud Storage Integration: Upload videos and images to the cloud for easy access and sharing.
• Stadiametric Rangefinder: Provides distance estimates for accurate tracking and targeting.

What’s in the Box:

• Pulsar AXION XG35 COMPACT Thermal Monocular (35mm, <40mK, 640x480px)
• APS3 Rechargeable Battery
• Power Adapter
• USB Type-C Cable with USB Type-A Adapter
• Carrying Case
• Hand Strap
• Quick User Manual
• Lens Cloth
• Warranty Sheet

Warranty:

Pulsar 3-year warranty

The Pulsar Axion XG35 Compact Hand-Held Thermal Monocular is the perfect solution for those who need powerful thermal imaging in a lightweight, portable form. With exceptional long-range detection, a variety of color palettes, and an intuitive user experience, this monocular is ready for any mission, day or night. Whether for professional surveillance, wildlife observation, or recreational use, the Axion XG35 excels in any environment.
