Pixfra Draco D225-4K LRF Multispectral Thermal Binoculars

Pixfra Draco D225-4K LRF Multispectral Thermal Binoculars

The Pixfra Draco D225-4K LRF Multispectral Thermal Binoculars are the most compact model in the Draco range. They combine thermal imaging, 4K day and night vision, and a laser rangefinder. Therefore, they are ideal for mobile users who value low weight and versatility.

This model is designed as an entry point into multispectral binoculars. However, it still delivers serious performance. As a result, hunters, wildlife observers, and security users get a capable all-in-one device without added bulk.

Key Features

Compact Thermal Performance

At the core of the D225-4K is a 256 × 192 VOx thermal sensor. It features a 12µm pixel pitch and ≤18mK sensitivity. Therefore, small heat differences remain visible in challenging conditions.

• Thermal resolution: 256 × 192
• NETD: ≤18mK @ f/1.0
• 25mm f/0.9 thermal lens
• Base magnification: 4.3×
• Digital zoom: 1–8×
• Detection range up to 1,300 m

As a result, the D225-4K performs well across woodland, farmland, and open terrain.

4K Day & Night Digital Optics

The D225-4K also features a 4K digital day/night channel. This allows confident identification in daylight and detailed viewing after dark.

• 1/1.8” CMOS sensor
• 3840 × 2160 resolution
• 55mm f/2.0 objective lens
• 5.5× base optical magnification
• Up to 44× total magnification

Additionally, automatic day/night switching ensures smooth operation from dusk to darkness.

Clear Viewing & Image Enhancement

Both channels are viewed through a high-resolution 0.49” OLED display. Therefore, the image remains bright and comfortable during long sessions.

• Display resolution: 1920 × 1080
• Binocular-style viewing experience
• High-contrast image output

Pixfra’s PIPS 3.0 image processing enhances both thermal and digital views. As a result, images appear sharper and more stable.

• AI noise reduction
• Improved detail clarity
• Multiple thermal colour palettes
• Adjustable digital viewing modes

Integrated Laser Rangefinder

A built-in Class 1 laser rangefinder provides accurate distance readings.

• Maximum range: 1,000 m
• Accuracy: ±1 m
• Ideal for planning and situational awareness

Therefore, users can assess distance quickly and safely.

IR Illuminator for Night Use

A detachable IR illuminator enhances digital night vision when ambient light is very low.

• Available in 850nm or 940nm
• Effective range up to 400 m
• Smart IR control reduces close-range glare

As a result, night-time identification becomes easier and more controlled.

Connectivity & Usability

The D225-4K is designed for fast and simple operation. Therefore, it performs well in real-world field conditions.

• Electronic Image Stabilisation (EIS)
• Defog mode
• Menu memory
• One-handed control layout
• Dual-band Wi-Fi (2.4 / 5 GHz)
• Pixfra app support
• 64GB internal storage

Power & Durability

Power is supplied by removable 18650 batteries. This allows flexible charging options in the field.

• Approx. 9 hours battery life at 25°C
• USB-C charging
• Power bank support
• Optional external charger

Additionally, the device is built for harsh environments.

• IP67-rated dust and water protection
• Operating temperature: –30°C to +55°C
• Weight: approx. 0.61 kg

Ideal Applications

• Hunting and pest control
• Wildlife observation
• Outdoor exploration
• Search and rescue
• Security and surveillance

Pixfra Draco D225-4K LRF Multispectral Thermal Binoculars Specifications

• Thermal Sensor: 256 × 192 VOx, 12µm, ≤18mK
• Thermal Lens: 25mm f/0.9
• Detection Range: ≈1,300 m
• Digital Sensor: 4K CMOS (3840 × 2160)
• Laser Rangefinder: 1,000 m, ±1 m
• Display: 0.49” OLED, 1920 × 1080
• Storage: 64GB internal
• Battery: Removable 18650
• Protection Rating: IP67
• Weight: 0.61 kg
• SKU: PIX-PFI-D225-4K
