Introducing the Infiray Tube TS60 LRF, the pinnacle of thermal riflescope technology by Infiray Outdoor. Boasting a state-of-the-art thermal sensor, this flagship device delivers unparalleled high-definition performance with industry-leading thermal sensitivity.
Equipped with a groundbreaking self-developed thermal sensor, the Tube TS60 features a remarkable 1280×1024 pixel resolution and a NETD of sub 18mk, setting a new standard in capturing minute temperature variations in challenging outdoor environments.
Experience the next level of clarity with the 1.03-inch, 2560×2560 round AMOLED display, offering seven distinct color palettes for an enhanced observation experience like never before.
With its advanced thermal sensor and high-definition display, the TS60 boasts an impressive 3100m long detection range, providing hunters with unprecedented advantages for long-range hunting experiences.
Included as standard is a ballistic laser rangefinder, enabling accurate distance measurement in the field and instant aiming solutions at any distance with the touch of a button.
Enjoy extended operating times with the integrated 6600mAh battery, with the option to add an additional 18650 standard battery for replaceable and rechargeable convenience, offering up to 9 hours of maximum operating time at 22℃.
Key Features:
- 1280×1024 UHD Thermal Imaging Sensor: Delivers high-resolution thermal imaging for exceptional clarity.
- 2560×2560, 1.03″ Round Display: Offers a sharp and detailed viewing experience with multiple color palettes.
- 60mm Germanium Lens: Provides 2x base magnification and an ultra-wide field of view (14.7° horizontal) for enhanced observation.
- LRF Upgrade Compatibility: Supports an optional ILR-1200-1 Tube LRF Bluetooth for ballistic calculation and precise distance measurement.
- Ballistic Calculator (with ILR-1200-1 LRF Module): Enables accurate aiming solutions based on measured distances.
- Includes QD Mounting System: Features a quick-detach mounting system from InfiRay for convenient setup and adjustment.
- Ultra-Long Battery Life: Offers up to 9 hours of continuous operation with a removable 18650 battery and optional battery charger.
Specifications:
Sensor:
- Type: Uncooled Vox
- Resolution: 1280×1024
- Pixel Pitch: 12 µm
- NETD: ≤18 mK
- Frame Rate: 50 Hz
Optics:
- Objective Lens: 60mm/F1.0
- Magnification: 2x ~ 16x
- Field of View: 14.7° x 11.7°
- Eye Relief: 50 mm
Display:
- Type: AMOLED 1.03”
- Resolution: 2560×2560
Range Performance:
- Detection Range: 3100 m
Laser Rangefinder (Upgradeable):
- Safety Class: According to IEC 60825-1:2014
- Measurement Accuracy: +/-1m
Environmental Characteristics:
- Degree of Protection: IP67
- Operating Temperature Range: -20°C ~ +50°C
Power Supply:
- Battery Type: 2x Internal (18650) / 6600mAh + replaceable 18650 battery/3200mAh
- Operating Time on Battery: 9 hours (at 22°C)
- External Power Supply: 5V (Type C)
Weight & Size:
- Dimensions: 384×104×77 mm
- Weight: 1000g
Warranty:
- Device: 3 years
- Batteries: 1 year
