THERMTEC ARES 360L LRF THERMAL SCOPE
Discover the advanced Ares LRF series by ThermTec, a fusion of innovative design and state-of-the-art thermal imaging technology. Equipped with ThermTec’s ultra-sensitive <25mk sensor, the Ares LRF series ensures rapid target detection and precise identification.
Adapt to various scenarios effortlessly with ThermTec’s industry-leading Dual Lens System. This system combines a wide 20mm lens with a high-magnification 60mm lens, allowing seamless transitions to meet changing demands.
Enhancing functionality, the integrated Laser Range Finder (LRF) offers accurate measurements up to 1000 meters. The Ares LRF is crafted with premium germanium glass and an F1.0 lens, ensuring sharp image quality even in challenging conditions.
Experience Versatility with the 20mm + 60mm Dual Lens
The ThermTec Ares 360L features both a 20mm and a 60mm lens, giving users the flexibility to switch between them effortlessly. The 60mm lens extends the shooting range significantly, while the 20mm lens is perfect for close encounters.
Crisp Imagery with the 12-Micron Sensor
With a 12-micron sensor, the Ares 360L delivers sharper images and increased identification distance, outperforming standard 17-micron sensors.
Precision Targeting with the Laser Range Finder
Achieve precise targeting with the integrated Laser Range Finder (LRF), providing accuracy within 1 meter for distances up to 1200 meters.
Key Features of the ThermTec Ares 360L LRF Thermal Scope
- Resolution: 384×288
- Pixel Pitch: 12µm
- NETD: ≤25mk
- Spectral Range: 8-14µm
- Frame Rate: 50Hz
- Objective Lens: 20/60mm, F/1.0
- Field of View: 13.1°x9.8° / 4.4°x3.3°
- Magnification: 1.8X / 5.5X
- Digital Zoom: 1.0-5.0X smooth & rapid zoom
- Eye Relief: 50mm
- Exit Pupil: 6mm
- Diopter: -5 ~ +5D
- Click Range, m @100m (H/V): 3.6m / 3.6m
- Reticle: 7 options
- Reticle Color: Black and white
- Display Type: AMOLED
- Resolution (Pixel): 1024×768
- Display Size: 0.39 inch
- Color Palette: 6 options
- Max. Recoil Power on Rifled Weapon: 6000J
- Mounting Brackets on Weapon: Standard 30mm rings
- RAV (Recoil Activated Video): Yes
- Auto Zeroing: Yes
- Manual Zeroing: Yes
- Zeroing Profiles: 5
- Picture-in-Picture: Yes
- Laser Ranging: 1000m
- Image Calibration: Via lens cover
- Photo/Video Playback: Yes
- Built-in Memory: 16GB
- Type C: Data transfer
- Wi-Fi: Yes
- Battery Type: Replaceable, 18650 or 18500 battery
- Built-in Battery: 5000mAh, rechargeable
- Battery Life: 12 hours
- Operating Temperature: -20℃ to +50℃
- IP Rating: IP67
- Weight: 1250g
- Dimensions: 438(L) x 84(W) x 105(H) mm
- External Cable: USB data cable
- Other Accessories: 2x standard 30mm rings, eyeshade, etc.
3 year Thermtec warranty and Support
