Pixfra Mile 2 M207 Thermal Monocular
£399.95
(£319.96 ex vat)
The Pixfra Mile 2 M207 thermal monocular is compact yet powerful, featuring a 256×192 resolution and <35mK NETD thermal sensor. With a 7mm f1.0 lens, it detects heat signatures up to 350m and offers an exceptionally wide 24° field of view. It features built-in video recording, Wi-Fi for easy device connectivity, and up to 8.5 hours of battery life.
- Call for our best prices
- Visit us to explore our product range
- Apple Pay / Google Pay / PayPal
- Fast free shipping on orders over £60
- Secure checkout
The Mile 2 M207 thermal imaging monocular packs a powerful punch for such a compact and lightweight device. With a 256×192, 12μm, <35mK NETD thermal sensor and a powerful 10mm f1.0 objective lens, this monocular will reveal even the smallest heat signature at a range of up to 500m. Plus, with a strong Wi-Fi connection, this device can connect to up to four smart devices, allowing for effortless group sharing at a range of up to 40m.
Key Features:
- 256×192,12μm, <35mK NETD thermal sensor
- 7mm f1.0 objective lens
- 350m detection range
- Exceptionally wide 24.0° FOV
- Built-in video recording
- Built-in Wi-Fi
- Seamless connectivity of up to 4 smart devices
Specifications:
- Thermal Sensor 256×192, 12μm, <35mK NETD
- Objective Lens 7mm f1.0
- Spectral Range 8 μm–14 μm
- Field of View H: 24.0°; V: 18.0°/H: 43.9 m; V: 32.9 m (@100 m)
- Focus Control Fixed-focal
- Close Focus Distance 1 m (3.28 ft)
- Detection Range Up to 350 m
- Magnification 1.1x
- Frame Rate 50 Hz
- Display 800 × 600, 0.32 inch OLED
- Color Palettes 6 (white hot/black hot/iron red/alarm/emerald/amber)
- Video Compression H.264
- Diopter –3 D to +1 D
- Eye Relief 13 mm (0.51 inch)
- Exit Pupil 5 mm (0.20 inch)
- Digital Zoom 1×, 2×, 4×, 8×
- Video Recording Yes
- Still Image Capture Yes
- Wi-Fi Hotspot Yes
- Hot Spot Tracking Yes
- Video Distance Measurement Yes
- FFC Calibration Auto, Manual, External Correction
- Standby Mode Yes
- DPC (Defective Pixel Correction Yes
- Storage Built-in 16GB
- Battery Type Rechargeable Lithium Battery
- Battery Life 8.5 hours (@ 25°C)
- Power Supply 5 VDC/2 A
- Port USB Type-C
- Overvoltage Protection Yes
- Operating Temperature –30 °C to +55 °C (–22 °F to +131 °F)
- Operating Humidity ≤95%
- Protection Grade IP67
- Packaging Dimensions 180.0 mm × 123.0 mm × 96.0 mm (7.09″ × 4.84″ × 3.78″) (L × W × H)
- Product Dimensions 149.0 mm × 56.6 mm × 50.3 mm (5.87″ × 2.23″ × 1.98″) (L × W × H)
- Gross Weight 760 g (1.68 lb)
- Net Weight 270 g (0.60 lb)
- SKU: PIX-PFI-M207
Learn More: Pixfra Mile 2 M210 Thermal Monocular
