Pard Leopard 640 LRF (35mm) Thermal Monocular

Pard Leopard 640 LRF (35mm) Thermal Monocular

The Pard Leopard 640 LRF Thermal Monocular is designed to deliver exceptional thermal imaging and performance, making it ideal for hunting, outdoor activities, and surveillance. Featuring a high-resolution 640×512 thermal sensor with NETD ≤20mK sensitivity, this compact monocular ensures precise target detection even in challenging environments. With an integrated 1000m laser rangefinder, image modes, and an IP67 rating, it provides optimal clarity and reliability in any weather conditions.

High-Resolution Thermal Imaging

The Leopard 640 LRF boasts an advanced 640×512 resolution thermal sensor, delivering remarkable clarity and detail for enhanced target detection. Its NETD ≤20mK sensitivity enables detection of even the smallest temperature differences, down to 0.02°C, ensuring you never miss a target.

Superior Display for Sharp, Clear Imagery

Equipped with a 1920×1080 AMOLED display, the Leopard 640 LRF offers vibrant, high-definition visuals, providing a crisp and clear image in any lighting conditions. Whether you’re tracking game or surveying your surroundings, the upgraded display ensures every detail is visible.

Compact & Lightweight for Ease of Use

Weighing just 360 grams, the Leopard 640 LRF is lightweight and ergonomically designed for comfort. Its compact build ensures long observation sessions without fatigue, making it ideal for extended use in the field.

Wide Field of View & Long Detection Range

With a 12.5° horizontal field of view and an impressive detection range of up to 1800 meters, this monocular offers superior target tracking, allowing you to cover more ground and identify targets quickly and efficiently. The 35mm objective lens and 2.2x optical magnification provide the perfect balance of clarity and range for various applications.

Integrated 1000m Laser Rangefinder

The Leopard 640 LRF comes equipped with a 1000-meter laser rangefinder, offering real-time distance measurements with high accuracy. This feature allows you to make more informed decisions while observing and tracking targets at various distances.

Versatile Modes for Different Environments

With 6 image modes (WT-HOT, BK-HOT, EDGE, RD-HOT, IN-HOT, SKY) and 3 scene modes (City, Rain, Forest), the Leopard 640 LRF is adaptable to a wide range of environmental conditions. Whether you’re in urban settings or dense forests, the scope automatically adjusts for optimal performance.

Rugged & Durable Design

The Leopard 640 LRF is built to withstand harsh conditions. It features an IP67 waterproof and dustproof rating, ensuring reliable performance even in extreme weather. The aluminum alloy housing and all-glass multi-coated lensoffer durability, while the 18650 rechargeable battery ensures long-lasting power during extended use.

Additional Features

• Hot Track: Quickly lock onto and track moving targets.
• Picture-in-Picture (PIP): Magnify a portion of the image for more precise targeting.
• Recoil-Activated Recording: Automatically records video when a shot is fired.
• Wi-Fi and USB Type-C: Seamlessly connect to apps like PardVision2 for file transfer and remote control.
• Gyroscope & E-Compass: For enhanced stability and orientation in the field.

Specifications

• Sensor:

  • Type: Uncooled VOx (Vanadium Oxide)
  • Resolution: 640 × 512 pixels
  • Pixel Size: 12 × 12 µm
  • NETD: ≤ 20mK (0.02°C)
  • Frame Rate: 50Hz
  • Detection Range: 1800 meters

• Optics:

  • Objective Lens: 35mm
  • Optical Magnification: 2.2x
  • Digital Zoom: 2x / 4x / 6x / 8x
  • Field of View (Horizontal): 12.5°
  • Field of View (Vertical): 10.0°
  • Field of View (Diagonal): 16.0°
  • Eye Relief: 20mm

• Display:

  • Type: AMOLED
  • Resolution: 1920 × 1080 pixels
  • Scene Modes: City, Rain, Forest
  • Image Modes: WT-HOT, BK-HOT, EDGE, RD-HOT, IN-HOT, SKY

• Photo & Video:

  • Photo Resolution: 1440 × 1080 pixels
  • Video Resolution: 1440 × 1080 pixels
  • Storage: Micro SD card (Max. 128GB)

• Main Functions:

  • Laser Rangefinder (LRF) Detection Range: 1000m (1200 yards)
  • Picture-in-Picture (PIP): Yes
  • Hot Track: Yes
  • Gyroscope: Yes
  • Loop Recording: Yes
  • E-Compass: Yes
  • Shutter: Mechanical Shutter
  • Microphone: Yes

• Connectivity:

  • USB Type-C: Yes
  • HDMI Output: Yes
  • Wi-Fi: Yes
  • Supported App: PardVision2

• Power Supply:

  • Battery Type: Lithium-Ion 18650 × 1
  • Operating Time: ≤ 6 hours
  • External Power Supply: USB Type-C

• Environmental:

  • Protective Class: IP67 (Waterproof & Dustproof)
  • Operating Temperature: -30°C to +55°C (-22°F to +131°F)

• Build:

  • Housing: Aluminum Alloy + Composite
  • Eyepiece: All-glass multi-coated lens

• Dimensions & Weight:

  • Dimensions (L × W × H): 169 × 58 × 48mm
  • Weight (with LRF & Battery): 360g

Warranty

• 2-Year Limited Warranty on all Night Vision Devices
• 3-Year Unlimited Warranty on all Thermal Devices

The Pard Leopard 640 LRF (35mm) Thermal Monocular is an advanced, compact, and reliable tool designed for a variety of outdoor applications. With its superior imaging capabilities, long detection range, and rugged build, it is the ultimate device for those seeking precision and performance in their thermal observations.
